Camera
- Image sensor : 8 MP CMOS / 1/2.7" type
- Lens focal length : 2.8 mm
- Maximum aperture : f/1.6
- Lens iris type : fixed
- Lens focal type : fixed
- Field of view : horizontal: 110° / vertical: 56° / diagonal: 126°
- DORI distance : Detection: 90 m / Observation: 36 m / Recognition: 18 m / Identification: 9 m
- Maximum illumination distance : white LED: up to 50 m / IR LED: up to 50 m
Video
- Resolution : 8 MP (3840 × 2160) / 6 MP (3072 × 1728) / 5 MP (2592 × 1944) / 5 MP (2944 × 1656) / 5 MP (2880 × 1620) / 4 MP (2560 × 1440) / 3 MP (2304 × 1296) / 2 MP (1920 × 1080) / 0.6 MP (1024 × 576)
- Frame rate : up to 20 fps
- Image rotation : 0° / 180°
- Video codec : H.265 / H.264
- Dynamic range : 120 dB (True WDR)
- Storage : microSD / Ajax NVR
Audio
- Built-in microphone
- Audio codec : G711-ULAW / G711-ALAW / G726 / G722
Intelligent video analytics
- Motion detection
- AI object detection : People / Pets / Vehicles
Network
- Port : 1 × RJ-45 self-adaptive Ethernet (10/100 Mbps)
- Protocol : HTTP / HTTPS / TCP/IP / IPv4 / IPv6 / SNMP / RTSP / UDP / DHCP / DNS / DDNS
- Interoperability : ONVIF (Profile S/T*) (* Profile T is supported for basic streaming and configuration. Advanced features such as metadata, event handling, or edge recording may not be available)
Key features
- Video protocol : JetSparrow
- Visual verification of Ajax alarms
- Privacy
Sabotage protection
- mTLS
- Authentication
- Secure Boot
- OTA signature verification
Power supply
- PoE standard : 802.3at/af
- PoE power consumption : maximum: up to 8.1 W / average: up to 7.0 W
- Power supply unit : 12 V⎓ ± 20% / 1 А
- 12 V DC power consumption : maximum: up to 7.0 W / average: up to 6.0 W
Enclosure
- Dimensions : 198 × 76 × 76 mm
- Weight : 550 g
- Operating temperature range : from −30 °C to +60 °C
- Operating humidity : up to 90%
- Protection class : IP65 / IK08
