System
- Main Processor : Industrial-grade processor
- Operating System : Embedded Linux
- Operating Interface : Web / Local GUI
AI
- AI by Recorder : Face detection / face recognition / perimeter protection / and SMD Plus
- AI by Camera : Face detection / face recognition / perimeter protection / SMD Plus / ANPR / people counting / stereo analysis / heat map
Perimeter Protection : Perimeter Performance AI by Recorder (Number of Channels) : 2 channels, 10 IVS rules for each channel
- Perimeter Performance of AI by Camera (Number of Channels) : All channels (8 targets/s)
Face Detection
- Face Attributes : Gender / age group / glasses / expressions / face mask / beard
- Face Detection Performance of AI by Recorder (Number of Channels) : 1 channel (up to 12 face images/s each channel)
- Face Detection Performance of AI by Camera (Number of Channels) : All channels (8 targets/s)
Face Recognition
- Face Database Capacity : Up to 10 face databases with 20,000 images / with a total capacity of 2.5 G. Name / gender / birthday / address / credential type / credential No. / countries & regions and state can be added to each face image
- Face Recognition Performance of AI by Recorder (Number of Channels) : 8-channel FD (by camera) + FR (by recorder) / image stream: 12 face images/s / 1-channel FD (by recorder) + FR (by recorder), video stream: 12 face images/s
- Face Recognition Performance of AI by Camera (Number of Channels) : All channels (8 targets/s)
SMD Plus
- SMD Plus by Recorder : 4 channels: Secondary filtering for human and motor vehicle / reducing false alarms caused by leaves / rain and lighting condition change
- SMD Plus by Camera : All channels (16 targets/s)
Audio and Video
- Access Channel : 8 channels
- Network Bandwidth : 80 Mbps incoming / 80 Mbps recording and 80 Mbps outgoing
- Resolution : 16 MP / 12 MP / 8 MP / 6 MP / 5 MP / 4 MP / 3 MP / 1080p / 960p / 720p / D1 / CIF
- Decoding Capability : AI disabled: 2-channel 16 MP@30 fps / 2-channel 12 MP@30 fps / 4-channel 8 MP@30 fps / 4-channel 6 MP@30 fps / 6-channel 5 MP@30 fps / 8-channel 4 MP@30 fps – AI enabled: 1-channel 16 MP@30 fps; 2-channel 12 MP@30 fps / 3-channel 8 MP@30 fps / 3-channel 6 MP@30 fps / 4-channel 5 MP@30 fps / 6-channel 4 MP@30 fps / 8-channel 1080p@30 fps
- Video Output : 1 HDMI / 1 VGA – HDMI: 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720 – VGA: 1920 × 1080, 1280 × 1024, 1280 × 720 *Simultaneous/heterogeneous video sources output for VGA and HDMI is configurable.
- Multi-screen Display : 1st Screen: 1/4/8/9 / 2nd Screen: 1/4/8/9
- Third-party Camera Access : Panasonic / Sony / Samsung / Axis / Pelco / Arecont / ONVIF / Canon
Compression Standard
- Video Compression : Smart H.265+ / H.265 / Smart H.264+ / H.264 / MJPEG
- Audio Compression : G.711a / G.711u / PCM / G726
Network
- Network Protocol : HTTP / HTTPS / TCP/IP / IPv4/IPv6 / UPnP / SNMP / UDP / SMTP / NTP / DHCP / DNS / IP Filter / PPPoE / DDNS / FTP / Alarm Server / IP Search (Support Dahua IP camera / DVR / NVS / etc.) / P2P / auto register
- Mobile Phone Access : iOS / Android
- Interoperability : ONVIF 22.06(Profile T / Profile S / Profile G) / CGI / SDK
- Browser : Chrome / IE9 and later / Firefox
Recording Playback
- Multi-channel Playback : Up to 8 channels
- Record Mode : General / motion detection / intelligent / alarm
- Backup Method : USB device and network
- Playback Mode : Instant playback / general playback / event playback / tag playback / smart playback
Alarm
- General Alarm : Motion detection / privacy masking / video loss / scene changing / PIR alarm / IPC external alarm
- Anomaly Alarm : Camera disconnection / storage error / disk full / IP conflict / MAC conflict / login locked and cybersecurity exception
- Intelligent Alarm : Face detection / face recognition / perimeter protection / SMD Plus / people counting / stereo analysis / heat map
- Alarm Linkage : Record / snapshot / IPC external alarm output / audio / buzzer / log / preset / email
Port
- Audio Input : 1-channel RCA
- Audio Output : 1-channel RCA
- Disk Interface : 1 SATA port, up to 16 TB.The maximum HDD capacity varies with environment temperature.
- USB : 2 (1 front USB 2.0 port / 1 rear USB 2.0 port)
- HDMI : 1
- VGA : 1
- Network Port : 1 (10/100 Mbps Ethernet port / RJ-45)
General
- Power Supply : 12 VDC / 2A
- Power Consumption : <7.8 W (without HDD)
- Net Weight : 0.84 kg
- Gross Weight : 1.43 kg
- Product Dimensions : 260 mm × 232.7 mm × 47.6 mm (W × L × H)
- Packaging Dimensions : 333 mm × 89 mm × 315 mm (W × L × H)
- Operating Temperature : –10 °C to +55 °C
- Storage Temperature : –20 °C to +60 °C
- Operating Humidity : 10%–93% (RH), non-condensing
- Installation : Rack / Desktop
- Certifications : FCC: 47 CFR FCC Part15 / SubpartB / Class A / CE-EMC: EN 55032:2015+A1:2020 / EN IEC 61000-3-2:2019+A1:2021 / EN 61000-3-3:2013+A1:2019+A2:2021 / EN 55035:2017+A11:2020 / EN 50130-4:2011+A1:2014 / CE-LVD: EN 62368-1:2014
