Technical Parameters
- Coupling Method : PV coupling
Input (PV)
- Maximum PV input power : 5kW (2.5kW * 2)
- Maximum input voltage : 1000V d.c.
- Operating voltage range :150V~800V d.c.
- Starting voltage : 150V
- Maximum PV current per string :24A
- Maximum operating current per string :12A
- Number of PV strings : 2
Output
- Supported solar inverter type : Single phase / Three phase
- Output voltage range : 150V~800V d.c.
- Maximum output power : 5kW
- Maximum output current : 24A
- Output current per string : 12A
Battery
- Battery material :LFP
- Nominal voltage : 800V
- Operating voltage range : 720V~960V
- Output voltage of the battery pack : 800V
- Capacity of each battery pack : 5.1kWh
- Maximum charging power : 2.5kW
- Maximum discharging power : 3.3kW
- Cooling method : Natural convection
Protection
- Direct current insulation resistance testing
- Input reverse polarity protection
- Direct current switch
- Overcurrent protection
- Overvoltage/Undervoltage protection
- Low/High temperature protection
Other Specifications
- Operating temperature range : -20°C~50°C
- Operating humidity : 0~100% RH
- Maximum operating altitude : 3000m
- Converter weight : 20kg
- Converter dimensions(W*D*H) : 680mm*201mm*230mm (±1mm)
- 1 battery pack weight : 59.2kg
- 1 battery pack dimensions(W*D*H) : 680mm*183mm*479mm (±1mm)
- Protection level : P65
- Communication method :RS485, Wi-Fi, WAN, Bluetooth
- Noise level : ≤35dB
Compliance
- Converter safety standard : IEC/EN62109-1
- Battery safety standard : IEC/EN62619, IEC/EN62040-1,IEC/EN62477-1, ISO13849
- Protective class : I
