Lenkeng HDMI Extender over Ethernet 70m 1080p LKV372N
, ,

Lenkeng HDMI Extender over Ethernet 70m 1080p LKV372N

42,00 €

This HDMI Extender includes a transmitter unit and a receiver unit, allows the HDMI signal to be transmitted up to 70 meters at 1080p resolution using a Cat6/6A/7 network cable. It adopts a point-to-point connection configuration, supports IR pass-back. It is perfect for outdoor advertising, monitor system, home entertainment, conference, etc.

  • 40 meters for 4K@30Hz signals
  • 70 meters for 1080p@60Hz signals





SKU: 23046 Categories: , , Brand:
  • Voltage/Current DC5V/500mA
  • Power consumption TX<1.5W； RX<1.5W
  • HDMI compliance HDMI 1.4
  • HDCP compliance HDCP 1.4
  • HDMI resolution 800×600、1024×768、1280×720、 1280×960、1366×768、1440×900、 1680×1050、1920×1080、480i@60Hz、 480p@60Hz、576i@50Hz、 576p@50Hz、720p@50/60Hz、 1080i@50/60Hz、 1080p@24/25/30/50/60Hz、 3840×2160@24/25/30Hz
  • Audio formats DTS、DTS-HD、PCM、LPCM
  • HDR Support
  • EDID through Support
  • IR Pass-back Frequency Range：20~60KHz
  • Input and output TMDS signal 0.7~1.2Vp-p(TMDS)
  • Input and output DDC signal 5Vp-p(TTL)
  • Cat6/6A/7 Transmission Distance 1080p@60Hz transmission 70 meters
  • 4K@30Hz transmission 40 meters
  • Electrostatic protection of the whole machine Implementation of the standard:
  • IEC61000-4-2
  • 1a Contact discharge level 2（±4KV）
  • 1b Air discharge level 3 (±8KV)
  • Working temperature -20~60℃
  • Storage temperature -30~70℃
  • Humidity (no condensation) 0～90%RH
  • Dimension 75.0(L) x 60.0(W) x 16.5(H) mm
  • Weight TX:127g RX:127g
  • Color Black
