Video & Audio
- Image Sensor : 1/2.49" CMOS sensor
- Video Resolution : Default: 3840X2160 (8.0 Megapixels) at 25 frames/sec
- Lens : f=4.0mm fixed; F=2.0, with IR-cut filter
- Video Format : H.265
- Field of View : Horizontal: 87° / Vertical: 44°
- Day & Night : IR-cut filter with auto-switching
- Night Vision : 30 meters (100 ft) (LED: 18pcs/14mil/850nm)
- Audio ; Audio recording
Power
- PoE : IEEE 802.3af, 48V Active
- DC Power : DC 12.0V⎓1A, <12W
Interface
- Power : DC power port
- System : Reset button
- Ethernet : One 10M/100Mbps; RJ45
- Storage : microSD card slot (Max. 256GB)
- Audio : Built-in microphone
Software Features
- Frame Rate : Mainstream: 2fps – 25fps (default: 25fps) / Substream: 4fps – 15fps (default: 10fps)
- Code Rate : Mainstream: 4096Kbps – 8192Kbps (default: 6144Kbps) / Substream: 64Kbps – 512Kbps (default: 256Kbps)
- Browser Supported : Edge, Chrome, Firefox, Safari
- OS Supported : PC: Windows, Mac OS / Smartphone: iOS, Android
- Smart Alarm : Motion detection; person detection; vehicle detection; pet detection
- Record Mode : Motion-triggered recording (default); scheduled recording; 24/7 recording
- Protocols & Standards : HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
- Maximal User Access : 20 users (1 admin account & 19 user accounts); support up to 12 simultaneous video streams (10 substreams & 2 mainstreams)
- Smart Home : Google Assistant
Working Environment
- Temperature : Operating temperature: -10°C ~ +55°C (14°F ~ 131°F)
- Humidity : Operating humidity: 10% ~ 90%
- Waterproof : IP67
Size & Weight
- Dimension : Φ105*95mm
- Weight : 467.5g
