System
- Main Processor : Embedded Processor
- Operating System : Embedded Linux OS
- Button Type : Mechanical
- Number of Buttons : 1
- Interoperability : ONVIF / CGI
- Network Protocol : RTSP / DNS / FTP / RTP / RTMP / SIP / SSH / HTTP/HTTPS / ONVIF
Basic
- Screen Type : Capacitive Touchscreen
- Display Screen : 5-inch display screen
- Screen Resolution : 720 (H) × 1280 (V)
- Camera : 1/2.8" 2 MP CMOS high-definition / low illumination / dual cameras
- Field of View : H: 119° / V: 66° / D: 142°
- WDR : 120 dB
- Noise Reduction : 3D NR
- Video Compression : H.264 / H.265
- Video Resolution : Main stream: 720P/D1/WVGA/CIF / Sub stream: 1080P/720P/D1/WVGA/CIF/QVGA
- Video Frame Rate : PAL: 25 fps / NTSC: 30 fps
- Video Bit Rate : 256 kbps–4,096 kbps
- Light Compensation : Auto IR
- Audio Compression : G.711a / G.711u / PCM
- Audio Input : 1 channel
- Audio Output : Built-in speaker
- Audio Mode : Two-way audio
- Audio Enhancement : Echo suppression/digital noise reduction
- Audio Bit Rate : 16 kHz, 16 bit
Function
- Communication Mode : Full digital
- Verification Method : Card / Password / Face Recognition / Bluetooth
- Frequency Range : 2400-2483.5 MHz
- Max. Transmission Power : CE EIRP : ≤20 dBm@2400-2483.5 MHz
- Bluetooth : Yes
- Bluetooth Standard : BLE (Bluetooth mode) / BT5.2 (Bluetooth version)
- Auto Snapshot : Yes
- Information Release : Receive and view text information released by the management center
- Elevator Control : Residents and visitors can call elevators. Permissions can also be granted to access floors through access control
- Leave Videos : Yes (SD card inserted in VTO is needed)
- Storage : Supports Micro SD card (up to 128 GB)
- Web Configuration : Yes
- Auto Registration : Yes
RFID
- Card Type : IC card / ID card
- Modulation Type : ASK
- Frequency Range : IC:13.56 MHz / ID:125 kHz
- Max. Transmission Power : IC:42 dBuA/m @10m / ID:66 dBuA/m @10m
Network
- Max. Transmission Power : ≤20 dBm@2400-2483.5 MHz
- Wi-Fi : Yes
- Wireless Standard : IEEE802.11b/802.11g/802.11n
- Wireless Frequency Range : 2.4 GHz
Performance
- Card Reading Distance : 0 cm–3 cm
- Face Recognition Height Range : 1.2 m–2.0 m
- Face Recognition Distance : 0.3 m–2.0 m
- Face Recognition Accuracy : 99.9%
- Face Recognition Time : 0.2 s
- Casing Material : Tempered glass / PC + ABS
Capacity
- Card Capacity : 100,000
- Face Image Capacity : 20,000
- User Capacity : 20,000
Port
- RS-485 : 1 channel
- Wiegand : 1 channel
- Alarm Input : 2 channels
- Alarm Output : 1 channel
- Power Output : Max 12 V / 1.5 A through an adapter / Max 12 V / 0.5 A through PoE
- Exit Button : 1 channel
- Door Status Detection : 1 channel
- Lock Control : 1 channel / open by default
- Network Port : 1 × 10 Mbps/100 Mbps Ethernet port
Alarm
- Tamper Alarm : Yes
General
- Appearance Color : Dark Silver
- Power Supply : Standard PoE / 12 VDC / 3 A
- Power Adapter : Optional
- Installation : Surface Mount
- Certifications : CE
- Accessory : Power supply (optional) / Surface Mounted (standard)
- Product Dimension : 186.8 mm × 81.4 mm × 23.3 mm (H × W × D)
- Protection : IP65 rated (Silicone sealant is required.)
- Operating Temperature : –30 °C to +60 °C
- Operating Humidity : 0%–90% (RH) / non-condensing
- Operating Environment : Outdoor
- Operating Altitude : 0 m–1,300 m
- Power Consumption : ≤ 8 W (standby) / ≤ 10 W (working). These two values of power consumption do not contain the output power.
- Gross Weight : 0.82 kg
- Storage Temperature : –20 °C to +70 °C
- Storage Humidity : 30%–75%
